5360X2225X2950mm
| 長X寬X高: | 5360X2225X2950mm(Without attachment header) |
| Working arm left and right movement stroke: | 1350mm |
| Left and right rotation angle of the working arm: | 180° |
| Attachment head rotation angle: | 360° |
| Number of driving wheels: | 4X2 |
| Cutting speed: | 5-15km/h |
| Engine structural type: | Four cylinder diesel fuel injection turbocharging |
| Automatic clutch transmission: | The maximum speed for each gear is 5km/h for gear 1, 12km/h for gear 2, 24km/h for gear 3, and 30km/h for gear 4. |
| Hydraulic oil tank capacity: | 200L |
| Diesel tank capacity: | 110L |
| Weed box capacity: | 2.8 cubic meters |
| Maximum Attachment Head Width: | 1800mm |
| Cutting outer width: | 5450mm(Comes with standard 1200mm accessory head) |
| Cutting the highest: | 7350mm(Comes with standard 1200mm accessory head) |
