| Base Dimensions： | L x W 1950 x 1750 mm |
| Trimming Working Speed | 5-15 km/h |
| Working Arm Rotation Range： | 360° |
| Attachment Head Rotation Range: | 300° |
| Diesel Tank Capacity: | 70 L |
| Tool Speed Range: | 2600-3500 r/min (up to 4500 r/min) |
| Engine: | 37 KW |
| Hydraulic Oil Tank Capacity: | 102 L |
| Single-pass Trimming Width: | 1800 mm |
| Minimum Trimming Height: | -500 mm |
| Mechanical Arm Length: | 3800 mm |
| Maximum Horizontal Trimming Distance: | 3550 mm (with 1800 mm attachment head) |
| Maximum Trimming Height: | 4500 mm + vehicle height (with 1800 mm attachment head) |
| Equipment Weight: | 1500 kg |
| Remote Control: | Handheld, with a range of 100 meters (line of sight) |
